Test Item

Test Ability

Radiated Emission

30MHz~40GHz

AC Line Conducted Emission

9kHz-108MHz

Disturbance Power

30MHz-300MHz

Insert loss

150kHz-1605kHz

3 loop antenna

9KHz-30MHz

Harmonic & Flicker

0~440VAC 50/60Hz , 5kVA/15kVA

EMF

0EN 50366

ESD

30kV

RS

80MHz~3.0GHz, 50V/m

EFT

4kV

SURGE

4KV

CS

150kHz~230MHz, 50V

PFMF

1~100A/m

DIP

100~270VAC 50/60Hz , 0~16A

Automotive electronics Immunity

ISO 7637

NO.

Item

contents

1

GB

GB4824 GB14023 GB4343.1 GB4343.2 GB17743 GB9254 GB 17799.3 GB 17799.4 GB 7260.2:2009 GB 13837 GB 14023 GB 15707 GB 8702 GB 9175 GB/T17618 GB/T18655 GB17625.1 GB17625.2 GB/T17626.2 GB/T17626.3 GB/T17626.4 GB/T17626.5 GB/T17626.6 GB/T17626.8 GB/T17626.11 GB/T 9383 GB/T 17799.1 GB/T 17799.2 GB/T 7349

2

GJB

GJB151A   GJB152A

3

CISPR

CISPR11 CISPR12 CISPR13 CISPR14-1 CISPR14-2 CISPR15 CISPR 16 CISPR22 CISPR24 CISPR25

4

EN

EN300 220-2 EN300 220-1 EN300 330-2 EN300 330-1 EN300 440-2 EN300 440-1 EN300 328 EN300 422 EN301 357-2 EN301 357-1 EN300 086 EN300 511 EN301 489-1 EN301 489-3 EN301 489-4 EN301 489-7 EN301 489-9 EN301 489-17 EN301 489-23 EN55011 EN55012 EN55013 EN55014-1 EN55014-2 EN55015 EN61547 EN55022 EN55024 EN 55025 EN 61000-6-1 EN 61000-6-2 EN 61000-6-3 EN 61000-6-4 EN 15194 EN 60601-1-2 EN 60945 EN 60947-1 EN 50130-4 EN 61204-3 EN 62040-2 EN 61326-1 EN 61326-2-1/2/3/4/5/6 EN 50131-3-2 EN 12015 EN 12016 EN 13309 EN ISO 14982 EN61000-3-2 EN61000-3-3 EN 61000-4-2 EN61000-4-3 EN61000-4-4 EN61000-4-5 EN61000-4-6 EN61000-4-8 EN61000-4-11

5

AS/NZS

AS/NZS 4268 AS/NZS CISPR14.1 AS/NZS CISPR13 AS/NZS CISPR15 AS/NZS CISPR22 AS/NZS 4251.1 AS/NZS 4251.2

6

FCC

FCC PART15 FCC PART18 FCC PART22 FCC PART24 FCC PART90 FCC PART95

7

IC

RSS 210 RSS Gen

8

E/e Mark

ECE Reg.No.10, 2004-104-EC

9

Other

RTCA/D0-160
