1. ELV Testing Overview:
ELV (End-of-Life Vehicle) refers to the End-of-Life Vehicles Directive. In the 1990s, attention to environmental issues related to automotive products increased significantly. To reduce the environmental impact of automotive products, protect the environment and resources, and save energy, various countries and regions have implemented environmental laws and regulations to strengthen the management of end-of-life vehicle recycling, improve recycling rates, reduce the environmental impact of end-of-life vehicles, and achieve sustainable growth in the automotive industry. How to handle end-of-life vehicles in an environmentally friendly and economical manner, promoting sustainable development in the automotive industry, has become a global focus, with waste management regulations becoming increasingly stringent.
2. ELV Basic Requirements:
Restrict the content and use of hazardous substances in automotive components and materials, and reduce the use of hazardous substances during vehicle design.
|
Content |
Maximum Allowable Concentration |
|
|
Heavy Metals |
Lead |
0.1% / 1000ppm |
|
Cadmium |
0.01% / 100ppm |
|
|
Hexavalent Chromium |
0.1% / 1000ppm |
|
|
Mercury |
0.1% / 1000ppm |
|
|
Organic Compounds |
Polybrominated Biphenyls (PBB) |
0.1% / 1000ppm |
|
Polybrominated Diphenyl Ethers (PBDE) |
0.1% / 1000ppm |
|
3. Differences Between European ELV Testing and Chinese ELV Testing:
|
European ELV Requirements (2000/53/EC) |
Chinese ELV Requirements |
||
|
Content |
Limit |
Content |
Limit |
|
Pb / Lead |
1000ppm |
Pb / Lead |
1000ppm |
|
Cd / Cadmium |
100ppm |
Cd / Cadmium |
100ppm |
|
Cr6+ / Hexavalent Chromium |
1000ppm |
Cr6+ / Hexavalent Chromium |
1000ppm |
|
Hg / Mercury |
1000ppm |
Hg / Mercury |
1000ppm |
|
|
PBB / Polybrominated Biphenyls |
1000ppm |
|
|
PBDE / Polybrominated Diphenyl Ethers |
1000ppm |
||
4. ELV Testing Methods:
|
Target |
Qualitative Analysis |
Quantitative Analysis |
||
|
Method |
Instrument |
Method |
Instrument |
|
|
Cadmium and Compounds |
X-ray Fluorescence |
EDX Energy Dispersive Spectrometer |
Atomic Emission Spectrometry |
ICP-AES Inductively Coupled Plasma Atomic Emission Spectrometer |
|
Lead and Compounds |
||||
|
Mercury and Compounds |
Diphenylcarbazide Spectrophotometry |
UV-Vis Spectrophotometer |
||
|
Hexavalent Chromium Compounds |
||||
|
Test Paper Colorimetry |
None |
|||
|
PBB/PBDE |
X-ray Fluorescence |
EDX Energy Dispersive Spectrometer |
Gas Chromatography-Mass Spectrometry |
GC-MS Gas Chromatograph-Mass Spectrometer |
