Metal Halide Lamp Testing

1. Introduction to Metal Halide Lamp Light Exposure Testing:

A metal halide lamp is a type of gas-discharge lamp. When electrified, metal halides can provide a spectral energy distribution very similar to that of direct and scattered sunlight. This method is highly efficient; by arranging multiple radiation sources in a specific configuration, a single illumination source effect can be achieved. The spectral distribution of metal halide lamps closely resembles the sunlight received at the Earth's surface. However, due to the large scale of equipment required for this type of light source simulation testing, it is primarily suitable for large-scale equipment such as complete vehicles and their components, as well as large electrical and electronic products.

Its typical spectral energy distribution is shown in the table below (filtered to simulate outdoor sunlight):

Spectral Wavelength (λ/nm)	Minimum /%	CIE NO.85:1989 Table/%	Maximum /%
280 ≤ λ ≤ 320 320 ≤ λ ≤ 360 360 ≤ λ ≤ 400 400 ≤ λ ≤ 520 520 ≤ λ ≤ 640 640 ≤ λ ≤ 800 800 ≤ λ ≤ 3000	0.3	0.36	0.7
	1.8	2.54	3.0
	2.4	3.76	4.4
	16.1	18.25	19.7
	14.9	18.14	18.3
	12.8	17.54	19.0
	33.7	39.41	50.5
280 ≤ λ ≤ 3000	100	100	100

2. Metal Halide Lamp Light Exposure Testing Standards:

GB/T 24333-2009, EN 60598, DIN 75220, IEC 60068-2-5, etc.

3. Application Areas of Metal Halide Lamp Light Exposure Testing:

Automobiles and affiliated products, 3D plastic components, chemical products, electronic products, aerospace products, optoelectronic products, roofs, window frames, and other components and finished products.

4. Equipment Parameters:

Irradiance: (800~1200) W/m²

Temperature Range: (-30~+100) °C

Humidity Range: (10%~90%) RH

Internal Chamber Dimensions: (570 × 600 × 550) mm

5. Shitong Testing Advantages:

Shitong Laboratory has a professional analysis and testing team capable of customizing testing plans for products. Relying on the center's advanced testing equipment and years of testing experience, and referencing relevant national and international standards, we conduct efficient and accurate testing. Ultimately, we synthesize the test data to form a comprehensive and authoritative testing analysis report.
